Cat12 CPE with 2.4G&5g WiFi Router

Basic Info

Model NO.	HIR204 Cat12 Version
Color	White
Certification	RoHS, CE
Network Mode	4G Cat12/Cat18/Cat20
Chipset	Mtk7621A, Mips1004kc, 880Mbps,Dual-Core
Model Version	Hir204 Cat12
Transport Package	Normal Export Carton
Specification	93.5x93.5x172.5mm
Trademark	Head Weblink
Origin	China
Production Capacity	100000/Month

Product Description

Product Application

Cat12 CPE with 2.4g&5g wifi RouterThe HiR204 series 5G indoor CPE supports the global 3G/4G LTE/5G network frequency bands and network standards of major countries and regions in the world, and supports the theoretical 4G rate of 300~600Mbps/100Mbps (DL/UL). Support 802.11b/g/n/ac, 2.4G/5.8G dual-band WIFI local networking and hotspot sharing. Support 4 Gigabit LAN ports, one RJ11 voice port, support VOIP and VOLTE voice calls.HiR204 has a built-in watchdog, never downtime, provides link maintenance function, self-recovery after disconnection, to ensure reliable and stable data connection, and keep it permanently online. Provide a safe and reliable high-speed data access channel for user equipment. High Light Chipset SolutionMDM9x50+MT7621A+MT7613+MT7603+Le9643Interface Specification1. 4G CAT12 2. 4* RJ45 for 1 WAN + 3 LAN 3. 802. 11a/b/g/n/ac 2T2R 2.4G /5G 4.1*RJ11 slic

Specification

Technical Standard
Hardware		Software
Chipset Solution MDM9x50+MT7621A+MT7613+MT7603+Le9643 Interface Specification 1. 4G CAT12 2. 4* RJ45 for 1 WAN + 3 LAN 3. 802. 11a/b/g/n/ac 2T2R 2.4G /5G 4.1*RJ11 slic		4G/ 3G; Ethernet; SMS; Firewall; MAC address Filtering; WiFi encryption authentication/WPS; IPv4/ IPv6 and IPv4v6 dual stack support; WAN/LAN configuration support; VPN client service (L2TP, PPTP) ; TR-069 services; WebUI;
Frequency Bands
Band Selection1		Band Selection2
LTE-FDD: B1/B3/B5/B7/B8/B20/B28 LTE-TDD: B38/B40/B41 HSPA+/WCDMA: B1/B3/B5/B8		LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B29/B30/B66/B71 LTE-TDD: B41 HSPA+/WCDMA: B2/B4/B5 Other Band can be customized;
Speed		WIFI
Cat12: UL 2CA 64 QAM ,DL 2CA 256QAM ,2x2MIMO LTE-FDD: Max 600Mbps (DL),Max 150Mbps (UL) LTE-TDD: Max 430Mbps (DL),Max 90Mbps (UL)		WLAN: IEEE 802.11a/b/g/n/ac WLAN: Built-in 2T2R
Environment Requirement
Operating Temperature:0ºC~40ºC Storage Temperature :-20ºC~65ºC Humidity:5%~95%, non-condensing Power Supply:Input power 100-240V, 50/60Hz Input power: 12VDC 1.5A
Basic feature		Operating system.
OpenWRT solution introduction Firmare Linux2.6 SDK , OpenWRT like network manage , internet , short massage , phonebook etc. •OpenWRT native Feature. •kernel open source and TW VUE WebUI.		Support all the function which in original OpenWRT.

Company Profile
Shenzhen Head Weblink Technology Co.,LTD

About USHead Weblink develops and delivers high-quality terminals for customers, covering 4G / 5G routers, 4G / 5G edge computinggateways, 4G DTU, 4G / 5G CPE, 2G / 3G / 4G LTE vehicle tracker, OBD, etc product. At the same time, the company provides customers with remote management of equipment, power/vehicle application management andother cloud platforms, APPs, and small programs. Provide customers with overall system solutions from terminals, edge computing, and cloud platforms, Provide reliable data link and monitoring operation and maintenance management for industrial equipment connection, securitymonitoring, power safety monitoring, energy efficiency management, etc. solution. FAQ1.How do i start purchase?You can email or contact with our online salesman, then get offer and shipping cost for your order, after you confirm, oursalesman will send u Invoice.After paymetn done, we will ship goods on time.2.Do u have stock for all item?Yes, we have sufficient stock and can do fast delivery.3. What about the delivery?
A: By express (DHL, UPS, FEDEX, TNT, EMS) to your door, By sea to your nearest port; By air to your nearest airport4. What about the payment?
A: By TT, Western Union, Moneygram or Paypal.5. What about the lead time?
A: For stock goods, 1-7 days after payment.6.WarrantyAll our product is brand new, we provide one year warranty.
