Global Travel Wireless 2g/3G/4G Mifi Lte Portable Hotspot 150Mbps Mobile WiFi Router with SIM Card Slot Color Screen
Portable Pocket Hotspot Mifi 2G/3G/4G LTE GSM Mobile WiFi Router with SIM Card Slot Main futures : 1. The WiFi router ca
Basic Info
| Model NO. | SHM1802F |
| Application | Enterprise, SOHO |
| Network | WCDMA |
| Performance | Non Line Speed Router |
| Item | 4G Lte Mobile WiFi |
| Modem | Lte-FDD/Tdd-Lte/WCDMA |
| Power | 802.11b/G/N: Max up to 150Mbps |
| Frequency | 2.4GHz |
| Communication System | Support Td-Lte/Lte FDD/WCDMA/GSM |
| Memory | Norflash 2GB |
| SIM Card | Standard SIM Card |
| 2T2R | Internal, WiFi Speed up to 150Mbps |
| Size | 109*60*20 mm |
| Weight | 105g |
| Battery | 1750mAh |
| Transport Package | Carton |
| Specification | 4G CPE |
| Trademark | Sunhans |
| Origin | China |
| Production Capacity | 10000PCS/Month |
Product Description
Portable Pocket Hotspot Mifi 2G/3G/4G LTE GSM Mobile WiFi Router with SIM Card SlotMain futures : 1. The WiFi router can support more than 30 frequencies, suitable for operators in more than 30 countries, support frequency customization, OEM & ODM. 2. WiFi hotspot designed with SIM function and also with sim card slot, more convenient to use. 3. Brand new MDM9x07 chipset, more stable signal and higher speed; 4. 802.11b/g/n: Max up to 150Mbps,2.4GHz . 5. Design lightweight, easy to carry, you can use anytime and anywhere. 6. Real 1750mAh battery for device.
Parameters:
| SKU | 0302SH100498 | |
| Model | SHM1802F | |
| Band/Mode | TDD-LTE: B38/39/40/41 FDD-LTE: B1/B3/B5/B7/B8/B20TD-SCDMA: B34/39 UMTS:B1/B2/B5/B8GSM Quad Band | The frequency bands can be customized |
| Type | Portable hotspot device with LCD | |
| Size(mm) | 109*60*20 | |
| Weight(g) | 105g | |
| System memory | NorFlash 2Gb | |
| HW Description | Item | Remark/Supplier |
| Main CPU or Co-CPU (MHz) | Marvell 1802 | |
| CPU (MHz) | 550MHz | |
| TDD-LTE | Cat4 150 Mbps DL / 50 Mbps UL | |
| FDD-LTE | Cat4 150 Mbps DL / 50Mbps UL | |
| Memory | ||
| System memory | NorFlash 2Gb | |
| External memory | up to 32GB | Micro-SD |
| WIFI | ||
| Frequency Band | 2.4GHz | |
| 802.11b/g/n | up to 150Mbps | Modes supported:802.11b mode802.11g only mode802.11n only mode802.11b/g only mode802.11b/g/n mode802.11n 1x1 (2.4GHz, 20MHz) |
| User amount | Max to 10 | Max to 10 |
| Interface | ||
| Antenna | 4G Main antenna4G MIMO Rx Diversity antennaWiFi antenna | Internal |
| LCD Display | 1.46" 128×128 TFT | |
| * USB | Micro USB | USB 2.0 High Speed |
| SIM/USIM Card slot | Yes | Standard 6 PIN SIM card interface, compliant with 3GPP 31.101 and 31.102 |
| Micro-SD Card slot | Yes | |
| L*H*W | 109*69*20 mm | |
| Weight | 105g | |
| Battery | Item | Remark/Supplier |
| Lion battery | 1750mAh | Li-on |
| Other Description | Item | Remark/Supplier |
| Electrical performance spec | ||
| RF Power Spec | Class 4 for UMTS/HSPA/LTE;Class 4 for GSM 850/900;Class 1 for GSM 1800/1900;Class E2 for EDGE 850/900/1800/1900 | |
| Power supply input | Yes | (5V-1A) |
| Power supply output | Yes | 5V-1A |
| Environmental reliability test condition | ||
| Normal Operation | 0°C to +45°C | |
| Restricted Operation | -10°C to +55°C | |
| Storage | -20°C to +70°C | |
About us
Our Service:
♦ Test process : every items will be testing before shipping, to make sure the quality. ♦ Short leading time: 1-2.5 working days for samples or small order, 10-15 working days for bulk order. ♦ One year warranty: for you without trouble of after-sales maintenance. ♦ Quality Guarantee: Return rate is only 0.001. ♦ Support small orders: help your business from small to big. ♦ OEM & ODM are welcome.
