New 4G Wireless Router with Broadband Internet 13 Km Distance

Basic Info

Model NO.	HDR100 V2
Color	White
Certification	RoHS, CE
4G Lte Antenna Gain	>10dBi
Antenna	2*2 4G/WiFi MIMO Antenna
Power Supply	Poe Power Supply, Supported Poe Output Via The Sec
Transport Package	Normal Export Carton
Specification	23*20*12cm
Trademark	Head Weblink
Origin	China
Production Capacity	100000/Month

Product Description

new 4G wireless router with broadband internet 13 km distance

High light
1). Waterproof and dustproof level. IP67
2). Lightning protection.
3). Dual LAN ports.
4). Provide Openwrt and SDK fireware version.

Frequency bands
* 4G LTE router.
HDR100 V2/4G Series
Version A
LTE FDD. B2,4,5,17
UMTS. 850/1900MHz

Version E
LTE FDD. B1,3,7,8,20
LTE TDD B38, B40
UMTS. 900/2100MHz
GSM. 900/1800MHz

Version C
LTE FDD. B1,3,7,8
LTE TDD B38, B39, B40, B41
UMTS. 900/2100MHz
TD-SCDMA. 1880~1920MHz & 2010~2025MHz
GSM. 900/1800MHz

Version JC
LTE FDD. B1,B3,B8,B18,B19
LTE TDD. B41
UMTS. B1,B6,B8
GSM. 900/1800MHz

Version JE
LTE FDD. B1,B8
UMTS. B1,B8
GSM. 900/1800MHz

* 3G router.
HDR100 V2/3G (WCDMA)
WCDMA. 850/1900MHz & 900/2100MHz
GSM. 850/900/1800/1900MHz

HDR100 V2/3G (EVDO).
EVDO 800MHz & 800/1900MHz
*Note.
We can provide customized frequency bands for customers.

Data rate

4G LTE router.
HDR100 V2/4G
FDD LTE. DL,100Mbps UL,50Mbps
TDD LTE. DL,50Mbps UL,25Mbps
WCDMA. DL 42Mbps UL5.76Mbps
TD-SCDMA. DL 2.8Mbps UL 2.2Mbps

Or
LTE Category 4 - 150 Mbps (DL)
LTE Category 4 - 50 Mbps (UL)

3G router.
1). HDR100 V2/3G (WCDMA)
WCDMA. DL 14.4Mbps, UL 5.76Mbps

2).HDR100 V2/3G (EVDO)
EVDO. DL 3.1Mbps, UL 1.8Mbps

Powerful function.

1. Supports multiple WAN connection mode, including static IP, DHCP,L2TP, PPTP, PPPOE, 3G/LTE.

2. Supports VPN client (PPTP, L2TP, VPN, IPSEC &GRE).

3. Supports remote management, SYSLOG, SNMP, TELNET, SSH, HTTPS and so on.

4. Supports APN/VPDN.

5. DHCP server and DHCP client, DHCP binding MAC address, DDNS, firewall and NAT DMZ host, QoS, traffic statistics, real-time display data transmission rate functions and so on.

6. Supports TCP/IP, UDP, FTP, HTTP network protocol.


Power supply
POE supply
Input. 100V~240V,50Hz~60Hz
Output. +12~+24V,1000mA

Conditions
Operating Temperature. -30ºC -- +70ºC
Operating humidity. 5%--95%
